Fan Accessory Type: Fan Motors |
Finish: Silver |
Glass Finish: Opal Frosted |
Motor Finish Method Type: Painted |
Slope: 27 Degrees |
Blade to Ceiling Height: 18.61''H |
Number of Blades: 8 |
Blade Pitch: 12.6 Degrees |
Compatible Blades: B7998-96BLW, B7998-96SLW |
Downrod Length: 12'' |
Light Kit Included: Yes |
Cap Included: Yes |
Ceiling to Bottom (No LK): 20.61'' |
Ceiling to Bottom (With LK): 20.61'' |
Motor Type: DC |
Motor Size: 153 x 25 |
Motor Speed: 16-Speed |
Reversible Motor: Yes |
Lead Wire: 80'' |
Compatible Controls: WFR7998 |
Included Control: TR205D |
Control Type: Handheld |
Reversing Control: Control |
Compatible Wall Controls: TW206D |
Compatible Accessories: CCK8002SLW, DR1-CPSL, DR1SS-18SLW, DR1SS-24SLW, DR1SS-36SLW, DR1SS-48SLW, DR1SS-60SLW, DR1SS-72SLW, SCB1-52 |
Canopy Dimensions: 6.3''D x 2.55''H |
Location Rating: Wet |
Bulb Base: Connector Pin |
Bulb Type: 18W LED Module |
Number of Lights: 1 - Light |
Wattage Per Bulb: 18W |
Voltage: 120V |
Voltage Cycles: 60HZ |
Color Temperature: 3000K |
Brightness: 1500 Lumens |
Color Rendering Index (CRI): 90 |
Energy cost (Low): 7 |
Energy cost (High): 10 |
Energy Use: 23W |
Airflow (Avg): 418 |
Airflow (Low): 1220 |
Airflow (Medium): 562 |
Airflow (High): 371 |
Current Draw (Low): 0.1 |
Current Draw (Medium): 0.3 |
Current Draw (High): 0.55 |
RPM (Low): 29 |
RPM (Medium): 49 |
RPM (High): 60 |
Watts (Low): 5 |
Watts (Medium): 19 |
Watts (High): 35 |
CFM (Avg): 9770 |
CFM (Low): 6148 |
CFM (Medium): 10513 |
CFM (High): 12965 |
DOE Classification: Large Diameter |
Exempt from DOE Procedure: Yes |
DOE-FTC Uploaded: Yes |
CEC Uploaded: Yes |
Regulated Product: Yes |
Fan Energy Star: No |
Light Kit Energy Star: No |
Safety Rating: UL/cUL |
