Fan Accessory Type: Fan Motors |
Finish: Black |
Glass Finish: Opal Frosted |
Motor Finish Method Type: Painted |
Slope: 27 Degrees |
Blade to Ceiling Height: 12.61''H |
Number of Blades: 8 |
Blade Pitch: 12.6 Degrees |
Compatible Blades: B7993-84BLW, B7993-84SLW, B7997-56BLW, B7997-56SLW, B7997-64BLW, B7997-64SLW, B7997-72BLW, B7997-72SLW |
Downrod Length: 6'' |
Light Kit Included: Yes |
Cap Included: Yes |
Ceiling to Bottom (No LK): 14.61'' |
Ceiling to Bottom (With LK): 14.61'' |
Motor Type: DC |
Motor Speed: 16-Speed |
Reversible Motor: Yes |
Lead Wire: 80'' |
Compatible Controls: WFR7997 |
Included Control: TR205D |
Control Type: Handheld |
Reversing Control: Control |
Compatible Wall Controls: TW206D |
Compatible Accessories: CCK8002BLW, DR1-CPBL, DR1SS-12BLW, DR1SS-18BLW, DR1SS-24BLW, DR1SS-36BLW, DR1SS-48BLW, DR1SS-60BLW, DR1SS-72BLW, SCB1-52 |
Canopy Dimensions: 6.3''D x 2.55''H |
Location Rating: Wet |
Bulb Base: Connector Pin |
Bulb Type: 18W LED Module |
Number of Lights: 1 - Light |
Wattage Per Bulb: 18W |
Voltage: 120V |
Voltage Cycles: 60HZ |
Color Temperature: 3000K |
Brightness: 1400 Lumens |
Color Rendering Index (CRI): 90 |
Energy cost (Low): 6 |
Energy cost (High): 9 |
Energy Use: 23W |
Airflow (Avg): 396 |
Airflow (Low): 614 |
Airflow (Medium): 346 |
Airflow (High): 168 |
Current Draw (Low): 0.06 |
Current Draw (Medium): 0.18 |
Current Draw (High): 0.46 |
RPM (Low): 28 |
RPM (Medium): 53 |
RPM (High): 76 |
Watts (Low): 3 |
Watts (Medium): 11 |
Watts (High): 32 |
CFM (Avg): 8927 |
CFM (Low): 2088 |
CFM (Medium): 3877 |
CFM (High): 5452 |
DOE Classification: LSSD |
Exempt from DOE Procedure: No |
DOE-FTC Uploaded: Yes |
CEC Uploaded: Yes |
Regulated Product: Yes |
Fan Energy Star: Yes |
Light Kit Energy Star: Yes |
Safety Rating: UL/cUL |
